Sender | Message | Time |
---|---|---|
10 Apr 2024 | ||
Kees van O | Yep π, maar realiseer dat er na, 'revisie', nog wat kosten voor tooling en meetmiddelen volgen. En als je bent als ik volgen er dan wat stappen motoren en control ... op de wensenlijst volgen π€ Let wel op dat de spindel een gangbare opname moet hebben anders gaan er onnodige kosten zitten in dure tools. | 17:30:26 |
Kees van O | Maar als ik het huidige bod zie lijkt me dat wel laag. Gewoonlijk zie ik roestbonken voor veelvouden vertrekken. Helaas heb ik er geen ruimte en nog zo wat voor π₯΄ | 17:35:19 |
11 Apr 2024 | ||
Kees van O | vmiguel: TER INFO - Het machine loopt ondertussen aardig richting 4000 π€¨ Hoewel geen verkeerde machine speelt in die setting dat het verschil met een nieuwe 'state of the art' met garantie toch kleiner wordt. Dit nog los van de vraag of je een machine van richting 2500 kg op de gedateerde houten vloer wil plaatsen. Overigens zag ik dat jij context van het lab zaken zelf wilde produceren. In die context formuleerde je behoefte aan een freesmachine. Goed om je te realiseren dat de aanwezige portaal frees-machine bij rustig gebruik meer kan dan een stuk hout bewerken. Wellicht eens bekijken wat de behoefte is en hoe deze te vervullen. Uiteindelijk leiden vele wegen naar het doel π | 08:08:58 |
vmiguel | Yeah itβs an auction it probably would go higher π , auctions are going crazy these days, sure the cnc can be used for light milling jobs on soft metals, with stainless I am no so sure, I just think a capable lathe and milling machine are basic fabrication tools and the FabLab should consider to have them in the long term | 08:13:47 |
vmiguel | * Yeah itβs an auction it probably would go higher π , auctions are going crazy these days, sure the cnc can be used for light milling jobs on soft metals, with stainless I am not so sure, I just think a capable lathe and milling machine are basic fabrication tools and the FabLab should consider to have them in the long term | 08:14:17 |
Kees van O | It is more a matter of the right cutting tools. I've done Stainless on small machines. You have to consider the forces on the machine and take light cuts and take the time. I expect it can be done on the portal as well. I agree that lath and mill would be fine. Point is that both require more than average craftsmanship. You don't have to be a machinist but there is a need for the 'right' attitude. Machines and tools are expensive as well as vulnerable and machining requires an attitude of thinking about how to get a job done with the tools at hand. π€ To be fair I would love it, but I doubt it has a place in Fablab Amersfoort. At least it is a challenge from multiple perspectives. And if so, it is more in the context of oud Micro Fabriek / Fablab Next Level. But the lack of interest to get that in place adds to my doubt. I have time and can do the things I like so I don't bother too much π Further more , situation dependent, you can 3D Print Stainless Steel Objects. However, I still lack an inert sintering kiln to start experimenting with it. | 09:52:13 |
vmiguel | there is an oven there that can be used for sintering with some adjustments by the way | 11:30:22 |
vmiguel | But regarding the machining shop is all a matter of proper training and some accountability, it is the same as the biolab, in the end they rely on specific knowledge and responsibility which the people that want to use them should know what they are doing | 11:33:52 |
Kees van O | More important the 'mission' of Fablab is to let people learn how to accomplish their requirements, to solve problems and to discover the way to get things done. I remember that 'some' time I struggled to make my own PCB's. Drawing the mask with inkt, and etching the copper away. An awful process ... There are alike routes for other (printing, milling, ...) as well. Quite often prototype your model by a 3D print using environment friendly filament before ordering the real thing. I follow this process before making the real thing. Often the 3D Printed version works out to be good enough and fulfil its purpose. Even better replacement is cheap and fast .... It is not the tooling but the learning curve: diagnose, analyse and solve the requirement. Collaboration and knowledge sharing helps us all! | 11:37:09 |
vmiguel | yes I understand, I am just coming here with eyes on the things we would like to do on a semiconductor lab, there the 3d print will not cut, when handling high vac and processing gases, sure you can order those parts but then we are talking big money | 11:39:59 |
Kees van O | I will check for that furnace. But the question is the 'leakage' it is not just ventilating air but creating an adequate flow of (expensive) inert gas. | 11:42:31 |
vmiguel | In reply to @kvoeveren:matrix.orgyes, i think covering the heaters with a stainless steel box you can create a sealed environment with minimum leakage | 11:44:06 |
Kees van O | high vac and processing gases ... I think that brass and plastic is more than adequate in most cases. I'm quite aware that things should not go out of hand by costs π€ | 11:45:45 |
vmiguel | In reply to @kvoeveren:matrix.orgsorry but you are quite wrong on that, only alu and stainless can be used on those situations, ptfe if the temperatures allow is possible too, brass is one of the materials you want to avoid on high vac systems | 11:47:45 |
Kees van O | To get a stainles steel case you need some expensive steel plate and you have to weld it (needs inert gas from two sides). An air tight door ??? | 11:47:47 |
vmiguel | In reply to @kvoeveren:matrix.orgyes sure, but is cheaper than building a hole furnace | 11:48:21 |
Kees van O | AL is easy to process; PTFE flows by nature ... | 11:48:57 |
Kees van O | But when you are in we can make an appointment and see what you need and whether it can be solved. I don't know everything and like to learn but I don't see why brass should not be fit for purpose. Even the adapters for Oxygen (I think 300 bar ...) are made from brass. | 11:53:15 |
vmiguel | brass can't be used, it has zinc | 12:00:02 |
vmiguel | zinc poisons high vac systems | 12:00:24 |
Kees van O | Ah thank you, know your materials π€¨ | 12:18:58 |
13 Apr 2024 | ||
Kees van O | Recentelijk (4 apr 2024) was op Fablab Amersfoort: Publiek het volgende aan de orde: | 11:06:06 |
Kees van O | For the robotics fan, just found out Xiaomi made a motion actuator, https://www.mi.com/cyber-gear | 11:20:52 |
Kees van O | Bovenstaande werd 4 apr 2024 aan de orde gesteld door vmiguel op Fablab Amersfoort: Publiek .... Ondertussen verder gespit blijkt er inderdaad wel enige informatie in de Engelse taal beschikbaar. Duidelijk is dat de Chinezen streven voortvarend de Robotica verder te ontwikkelen. Dit ongetwijfeld vanuit de druk van vergrijzing en oplopende arbeidskosten. Tegelijkertijd is het interessant dat in deze MIT licenties een rol spelen. Ooit was Nederland 'up to date' met mechanisering van de productie. Dit betrof met name massa productie. Vanwege de arbeidskosten werd outsourcing naar goedkope lonen landen 'bon ton'. [Hierop kom ik nog terug]. Robotisering is de bakermat voor een tegenbeweging. Tegelijk moeten we ons realisering dat dit niet uitsluitend massa productie faciliteert maar ook klein serie gewijs lokaal produceren. | 11:21:02 |
Kees van O | * Bovenstaande werd 4 apr 2024 aan de orde gesteld door vmiguel .... Ondertussen verder gespit blijkt er inderdaad wel enige informatie in de Engelse taal beschikbaar. Duidelijk is dat de Chinezen streven voortvarend de Robotica verder te ontwikkelen. Dit ongetwijfeld vanuit de druk van vergrijzing en oplopende arbeidskosten. Tegelijkertijd is het interessant dat in deze MIT licenties een rol spelen. Ooit was Nederland 'up to date' met mechanisering van de productie. Dit betrof met name massa productie. Vanwege de arbeidskosten werd outsourcing naar goedkope lonen landen 'bon ton'. [Hierop kom ik nog terug]. Robotisering is de bakermat voor een tegenbeweging. Tegelijk moeten we ons realisering dat dit niet uitsluitend massa productie faciliteert maar ook klein serie gewijs lokaal produceren. | 11:21:55 |
20 Apr 2024 | ||
Kees van O | Ik zou nog terug komen op: Vanwege de arbeidskosten werd outsourcing naar goedkope lonen landen 'bon ton' ... Wat ik bedoel is dat als je gaat outsourcen: laat ze dan geen makkelijk te verbeteren arbeidsintensieven producten maken ... In de volgende plaatjes zien we een PC-speaker box en een 'volume regelaar' (slechts een potmetertje). Maar wel zodanig ontworpen dat de electrische schroevendraaier snel zal slijten. Ik telde 7 schroeven in het speakertje (plus aantal lijm verbindingen) en zelfs 8 schroeven om de omsluiting voor het potmetertje samen te voegen ... | 16:31:09 |
