10 Jul 2020
@sawjan:matrix.orgsawjanJust out of curiosity: What are you working on?16:39:51
@drid:matrix.orgdridCOMMS16:40:16
@drid:matrix.orgdridUHF and S-Band16:40:29
@sawjan:matrix.orgsawjannice!16:40:42
@sawjan:matrix.orgsawjanS-Band?16:40:54
@sawjan:matrix.orgsawjanwe should talk about power budget ;)16:41:04
@drid:matrix.orgdridShould I add the I2C too, they seem to be common amongst all boards16:41:06
@sawjan:matrix.orgsawjan
In reply to @drid:matrix.org
Should I add the I2C too, they seem to be common amongst all boards
yes
16:41:21
@drid:matrix.orgdridAlso fixed H2 can bus position (based on kicad template)16:46:22
@sawjan:matrix.orgsawjanWas it different to the table?16:47:52
@drid:matrix.orgdridit was in pins 2 and 416:50:14
@sawjan:matrix.orgsawjanCAN_A_L should be pin 1 and CAN_A_H on pin 3, to match gomspace16:54:40
@drid:matrix.orgdridOh so both document and kicad template are incorrect16:55:30
@sawjan:matrix.orgsawjanprobably16:55:38
@sawjan:matrix.orgsawjanI don't have kicad opened at the moment so I don't see what has been implemented there. But of course chances are that I made a mistake when creating the board template16:56:45
Download image.png
16:57:18
Download image.png
16:57:25
@drid:matrix.orgdridfrom template16:57:28
@sawjan:matrix.orgsawjanthink I created the template during the 2018 chaos communication congress. maybe I was drunk...16:59:28
@drid:matrix.orgdridSo what do u think about making the connector a symbol with named pins?17:01:05
@sawjan:matrix.orgsawjanI trying to think if I had a reason to deviate from what gomspace is doing17:01:31
@drid:matrix.orgdridIt makes sense to be on 1 and 3, easier to have equal track lengths17:02:15
@sawjan:matrix.orgsawjanyep, true17:04:24
@sawjan:matrix.orgsawjanlet's change it to 1 and 3 for both CANs17:04:42
@sawjan:matrix.orgsawjanwhy do you want to implement S-Band and UHF and not VHF/UHF?17:05:59
@drid:matrix.orgdridDone, there is an MR waiting :-)17:07:37
@drid:matrix.orgdridVHF is a bit overcrowded17:09:19
@sawjan:matrix.orgsawjan
In reply to @drid:matrix.org
Done, there is an MR waiting :-)
done :)
17:54:48
@rayan:hackerspaces.berayan 20:06:38
11 Jul 2020
@gustav:ggc-project.degustav 10:31:19
