#%% Imports
from build123d import *
import gridfinity_build123d as gfb
from ocp_vscode import show, show_object, reset_show, set_port, set_defaults, get_defaults
set_port(3939)
set_defaults(axes=True, axes0=True)


#%% 1x Breadboard-60 Holder
with BuildPart() as bb1x60:
  base = gfb.Base(
    grid=[
      [True, True, True, True],
      [True, True, True, True]
    ],
    features=[gfb.MagnetHole()],
    align=(Align.MIN, Align.MIN, Align.MIN)
  )

  with BuildSketch(Location((0, 0, base.bounding_box().size.Z))) as spare_bin_base:
    RectangleRounded(bb1x60.part.bounding_box().size.X, 24.0, 4, align=(Align.MIN, Align.MIN))
    offset(amount=-1.0, mode=Mode.SUBTRACT)
  extrude(amount=10.0)
show(bb1x60)
bb1x60.part.export_stl('output/gf_electronics_bb1x60.stl')

#%% STM32 Nucleo-64
nucleo64_width = 70.0
pillar_height = 9.0

with BuildPart() as stm32nucleo64:
  base = gfb.Base(
    grid=[
      [True, True],
      [True, True]
    ],
    features=[gfb.MagnetHole()],
    align=(Align.MIN, Align.MIN, Align.MIN)
  )

  # Mounting pillars
  base_top = Location((0, 0, base.bounding_box().size.Z))
  with BuildSketch(base_top) as pillars_sk:

    # Top left hole as origin
    with Locations((26.5, ((base.bounding_box().size.Y - nucleo64_width) / 2) + 11)):
      with Locations([
        (0, 0),
        (1.3, 48.2),
        (52.1, 33)
      ]):
        Circle(radius=4)
        Circle(radius=2, mode=Mode.SUBTRACT)
  extrude(amount=pillar_height)

  wall_length = base.bounding_box().size.Y
  with BuildSketch(base_top) as walls_sk:
    add(base.faces().sort_by(Axis.Z)[-1])
    with Locations((base.bounding_box().size.X / 2, base.bounding_box().size.Y / 2)):
      Rectangle(wall_length, nucleo64_width + (1.0 * 2), align=(Align.CENTER, Align.CENTER), mode=Mode.SUBTRACT)
  extrude(amount=pillar_height + 2.0)  # flush with PCB

show(stm32nucleo64)
stm32nucleo64.part.export_stl('output/gf_electronics_stm32nucleo64.stl')
